Circuit Color is a simple application to find out the color code of the electrical conductors. It eliminates the use of cheat sheets or mental calculations or any other method you use now to determine the appropriate color of the circuit.
120V / 240V - 42 circuits*
120V / 208V - 126 circuits*
277V / 480V - 126 circuits*
Add as many panels as you want.
+Single Phase or Three Phase
Choose the phase colors and combinations
+Black, Red, Blue
+Brown, Orange, Yellow
+Pink, Tan, Purple
+White, Green, Gray
Choose the numbering style.
+Single Sided panels numbered down one side.
+Double Sided panels with conventional "zig zag" numbering.
Choose the number of circuits.
+84 for two conventional panels
+whatever number you want
The applications Circuit Colors was published
in the category Productivity on 2011-01-06 and
was developed by Francisco Alcala.
This application file size is 16.61 MB. Circuit Colors current version is 4.1 and works well on
IOS 9.0 and high versions.
Thank you to Mr. L. Hughes for finding a nasty little bug that would not let you change the number of circuits in a panel.
That bug has been squashed.
